SPBW03G-05

Mean Well DC/DC converter series SPBW03

Regulated DC/DC converters in a SIL6 housing with 3W, a remote ON/OFF control and an input voltage ratio of 4:1. These devices require no minimum load and are protected against short circuit (continuous), input undervoltage as well as overload. They are suitable for PCB mounting and comply with EN55032 class B (without additional components). We offer the following types of this Mean Well series: SPBW03F-03, SPBW03F-05, SPBW03F-12, SPBW03F-15, SPBW03G-03, SPBW03G-05, SPBW03G-12 and SPBW03G-15.

  • single output
  • output: 3W
  • output voltage tolerance: ±1,5%
  • maximal ripple and noise: 50mVpp
  • withstand voltage: 1500V DC
  • operating temperature: -40 to +85°C
  • weight: 4,8g
SPBW03G-05, 3 W, SIL 8 housing, SPBW03 series by Meanwell

SPBW03G-05

110395 SPBW03G-05 SPBW03G-05 4711287478777 Mean Well DC/DC converter series SPBW03. Regulated DC/DC converters in a SIL6 housing with 3W, a remote ON/OFF control and an input voltage ratio of 4:1. These devices require no minimum load and are protected against short circuit (continuous), input undervoltage as well as overload. They are suitable for PCB mounting and comply with EN55032 class B (without additional components). We offer the following types of this Mean Well series: SPBW03F-03, SPBW03F-05, SPBW03F-12, SPBW03F-15, SPBW03G-03, SPBW03G-05, SPBW03G-12 and SPBW03G-15.  single output output: 3W output voltage tolerance: ±1,5% maximal ripple and noise: 50mVpp withstand voltage: 1500V DC operating temperature: -40 to +85°C weight: 4,8g

Specifications

manufacturer
Manufacturer's name SPBW03G-05
GTIN 4711287478777
Input voltage [V] 18...75
Output voltage [V] 5
Output current range [mA] 0...600
Efficiency [%] 82
Data Sheet

Unit price

7,89 €

Volume discounts

Quantity Unit price
50 + 7,29 €

Stock: 438
Further delivery:
CW 18/2025
