SDR-75-12

Mean Well DIN rail power supply series SDR-75

Switching power supplies in an enclosed housing with 75W, an LED indicator, a universal input and screw terminals (touch guard). These devices are suitable for DIN rail mounting and are protected against overload (auto recovery), overvoltage as well as short circuit. They have a fanless design and comply with EN61000-6-2, EN50082-2, EN62368-1, EN55032 class B, EN61204-3 class B, EN61000-3-2 as well as EN61000-3-3. We offer the following types of this Mean Well series: SDR-75-12, SDR-75-24 and SDR-75-48.

  • single output
  • output: 75,6 to 76,8W
  • input voltage: 88 to 264V AC (47 to 63Hz), 124 to 370V DC
  • maximal input inrush current: 50A
  • peak power: 112,5W (3s)
  • leakage current: <1mA
  • output voltage adjustment: +15%
  • overload protection: 110 to 150%
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 500V AC
  • operating temperature: -30 to +70°C
  • weight: 510g
Mean Well SDR-75 series

SDR-75-12

41538 SDR-75-12 SDR-75-12 4711287422329 Mean Well DIN rail power supply series SDR-75. Switching power supplies in an enclosed housing with 75W, an LED indicator, a universal input and screw terminals (touch guard). These devices are suitable for DIN rail mounting and are protected against overload (auto recovery), overvoltage as well as short circuit. They have a fanless design and comply with EN61000-6-2, EN50082-2, EN62368-1, EN55032 class B, EN61204-3 class B, EN61000-3-2 as well as EN61000-3-3. We offer the following types of this Mean Well series: SDR-75-12, SDR-75-24 and SDR-75-48. single output output: 75,6 to 76,8W input voltage: 88 to 264V AC (47 to 63Hz), 124 to 370V DC maximal input inrush current: 50A peak power: 112,5W (3s) leakage current: &lt;1mA output voltage adjustment: +15% overload protection: 110 to 150% withstand voltage I/P-O/P: 3000V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 500V AC operating temperature: -30 to +70°C weight: 510g

Specifications

manufacturer
Manufacturer's name SDR-75-12
GTIN 4711287422329
Output voltage [V] 12
Phase 2 phase
Efficiency [%] 88,5
Output current range [A] 0...6,3
Output voltage tolerance: [%] 1
Output power [W] 75,6
Ripple [mVp-p] 100
Data Sheet

Unit price

27,69 €

Volume discounts

Quantity Unit price
50 + 25,99 €

Stock: 107
Further delivery:
CW 17/2025
