NTS-300-248EU

Mean Well DC/AC converter series NTS-300

Inverters with 300W, a pure sine wave output (THD<3%), a remote ON/OFF function as well as an alarm function in case of a low battery voltage. These devices have an adjustable output voltage and are protected against overtemperature, short circuit as well as overvoltage. They switch off automatically in case of a deeply discharged battery and comply with IEC62368-1, EN62368-1 as well as EN55032 class A. We offer the following types of this Mean Well series: NTS-300-212EU, NTS-300-224EU and NTS-300-248EU.

  • output: 300W
  • selectable output voltage: 200/220/230/240V AC
  • output voltage tolerance: ±3%
  • output frequency: 50/60Hz
  • output frequency tolerance: ±0,1%
  • curve shape: pure sine wave (THD<3%)
  • connection type: EU type F
  • operating temperature: -20 to +65°C
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage O/P-FG: 1500V AC
  • dimensions: 210x130x55mm
  • weight: 1300g
NTS-300-248EU, Mean Well DC/AC converters, 300W, pure sine wave, NTS-300 series

NTS-300-248EU

237703 NTS-300-248EU NTS-300-248EU 4711287466897 Mean Well DC/AC converter series NTS-300. Inverters with 300W, a pure sine wave&nbsp;output (THD&lt;3%), a remote ON/OFF function as well as an alarm function in case of a low&nbsp;battery voltage. These devices have an adjustable output voltage and are protected against overtemperature, short circuit as well as overvoltage. They switch off automatically in case of a deeply discharged battery and comply with IEC62368-1, EN62368-1 as well as EN55032 class A. We offer the following types of this Mean Well series:&nbsp;NTS-300-212EU, NTS-300-224EU and NTS-300-248EU. output: 300W selectable output voltage: 200/220/230/240V AC output voltage tolerance:&nbsp;&plusmn;3% output frequency: 50/60Hz output frequency tolerance:&nbsp;&plusmn;0,1% curve shape: pure sine wave (THD&lt;3%) connection type: EU type F operating temperature: -20 to +65&deg;C withstand voltage&nbsp;I/P-O/P: 3000V AC withstand voltage O/P-FG: 1500V AC dimensions: 210x130x55mm weight: 1300g

Specifications

manufacturer
Manufacturer's name NTS-300-248EU
GTIN 4711287466897
Input voltage range [V] 40...66
Efficiency [%] 93
Nominal voltage [V] 48
Rated input current [A] 8
Data Sheet

Unit price

95,89 €

Volume discounts

Quantity Unit price
50 + 92,69 €

Stock: 62
Further delivery:
CW 12/2025
