NID65-5

Mean Well DC/DC converter series NID65

Non-isolated DC/DC converters in an open frame SIL housing with 65W, a remote ON/OFF control and a regulated output voltage. These devices are suitable for PCB mounting and are protected against overload, overvoltage as well as short circuit. They have a fanless design and comply with EN62368-1, EN55032 class A as well as EN55032 class B. We offer the following types of this Mean Well series: NID65-5, NID65-12, NID65-15 and NID65-24.

  • single output
  • output: 32,5 to 64,8W
  • overload protection: 120 to 150%
  • operating temperature: -30 to +85°C
  • weight: 19g
NID65-5, Mean Well DC/DC converters (open frame), 65W, SIP, NID65 series

NID65-5

113284 NID65-5 NID65-5 4711287465913 Mean Well DC/DC converter series NID65. Non-isolated DC/DC converters in an open frame SIL housing with 65W, a remote ON/OFF control and a regulated output voltage. These devices are suitable for PCB mounting and are protected against overload, overvoltage as well as short circuit. They have a fanless design and comply with EN62368-1, EN55032 class A as well as EN55032 class B. We offer the following types of this Mean Well series: NID65-5, NID65-12, NID65-15 and NID65-24. single output output: 32,5 to 64,8W overload protection: 120 to 150% operating temperature: -30 to +85°C weight: 19g

Specifications

manufacturer
Manufacturer's name NID65-5
GTIN 4711287465913
Input voltage [V] 10,5...53
Output voltage [V] 5
Efficiency [%] 93
Output current range [A] 0...6,5
Output voltage tolerance: [%] ±2
Ripple [mVp-p] 100
Data Sheet

Unit price

10,69 €

Volume discounts

Quantity Unit price
50 + 9,89 €

Stock: 0
Next incoming goods:
CW 07/2025
140 units

Further delivery:
CW 18/2025
