NGE100

Mean Well plug-in power supply series NGE100

Plug-in switching power supplies in a compact housing with 100W, a low idle power (<0,3W), energy efficiency Level VI, protection class II and a universal input. These fast chargers have two Quick Charge USB-A ports as well as two USB-C ports with Power Delivery function (up to max. 100W) and are protected against overload, overtemperature as well as short circuit. They have interchangeable AC plugs (included), an auto detection for loads between 5 and 20V, support QC2.0, QC3.0 as well as PD3.0 and comply with EN62368-1 as well as EN55032 class B. We offer the type NGE100 of this Mean Well series.

  • quad output
  • output: 100W
  • input voltage: 90 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 95A
  • input current: 0,8A
  • operating temperature: -30 to +70°C
  • dimensions: 62x30x85,5mm
  • weight: 338g
NGE100, Mean Well plug-in switching power supplies, 100W, quad output, energy efficiency Level VI, NGE100 series

NGE100

245775 NGE100 NGE100 Mean Well plug-in power supply series NGE100. Plug-in switching power supplies in a compact housing with 100W, a low idle power (&lt;0,3W), energy efficiency Level VI, protection class II and a universal input. These fast chargers have two Quick Charge USB-A ports as well as two USB-C ports with Power Delivery function (up to max. 100W) and are protected against overload, overtemperature as well as short circuit. They have interchangeable AC plugs (included), an auto detection for loads between 5 and 20V, support QC2.0, QC3.0 as well as PD3.0 and comply with EN62368-1 as well as EN55032 class B. We offer the type NGE100 of this Mean Well series. quad output output: 100W input voltage: 90 to 264V AC (47 to 63Hz) maximal input inrush current: 95A input current: 0,8A operating temperature: -30 to +70°C dimensions: 62x30x85,5mm weight: 338g

Specifications

manufacturer
Manufacturer's name NGE100
Output voltage [V] 5...20
Efficiency [%] 88
Output current [A] 0,9...5
Output voltage tolerance: [%] ±5/±4
Output power [W] 100
Ripple [mVp-p] 200
Data Sheet

Unit price

51,89 €

Volume discounts

Quantity Unit price
50 + 50,19 €

Stock: 119
Further delivery:
CW 12/2025
