NDR-120-48

Mean Well DIN rail power supply series NDR-120

Switching power supplies with 120W, a universal input and an LED indicator for DC OK. These devices are suitable for DIN rail mounting and are protected against overload (auto recovery), overvoltage as well as short circuit. They have touch-protected screw terminals and comply with UL508, EN61000-6-2, EN50082-2, EN62368-1 as well as EN55032 class B. We offer the following types of this Mean Well series: NDR-120-12, NDR-120-24 and NDR-120-48.

  • single output
  • output: 120W
  • input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC
  • maximal input inrush current: 35A
  • leakage current: <1mA
  • output voltage adjustment: +15%
  • overload protection: 105 to 130%
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 500V AC
  • operating temperature: -20 to +70°C
  • weight: 600g
NDR-120-48, Mean Well DIN rail switching power supplies, 120W, NDR-120

NDR-120-48

45036 NDR-120-48 NDR-120-48 4711287422275 Mean Well DIN rail power supply series NDR-120. Switching power supplies with 120W, a universal input and an LED indicator for DC OK. These devices are suitable for DIN rail mounting and are protected against overload (auto recovery), overvoltage as well as short circuit. They have touch-protected screw terminals and comply with UL508, EN61000-6-2, EN50082-2, EN62368-1 as well as EN55032 class B. We offer the following types of this Mean Well series: NDR-120-12, NDR-120-24 and NDR-120-48. single output output: 120W input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC maximal input inrush current: 35A leakage current: &lt;1mA output voltage adjustment: +15% overload protection: 105 to 130% withstand voltage I/P-O/P: 3000V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 500V AC operating temperature: -20 to +70°C weight: 600g

Specifications

manufacturer
Manufacturer's name NDR-120-48
GTIN 4711287422275
Output voltage [V] 48
Efficiency [%] 89
Output current range [A] 0...2,5
Output voltage tolerance: [%] 1
Output power [W] 120
Ripple [mVp-p] 150
Data Sheet

Unit price

22,29 €

Volume discounts

Quantity Unit price
50 + 20,89 €

Stock: 1702
Next incoming goods:
CW 03/2025
1000 units

Further delivery:
CW 16/2025
