MDS15A-05

Mean Well DC/DC converter series MDS15

Converter modules in a 2x1 inch DIL housing with 15W and an input voltage ratio of 2:1. These devices have a low leakage current of less than 5µA, do not require a minimum load and are protected against overload (auto recovery) as well as short circuit (continuous). They are suitable for direct PCB mounting as well as for medical applications (2xMOPP) and comply with IEC60601-1 and EN55011 class A. We offer the following types of this Mean Well series: MDS15A-05, MDS15A-12, MDS15A-15, MDS15A-24, MDS15B-12, MDS15B-15, MDS15B-24, MDS15C-05, MDS15C-12, MDS15C-15 and MDS15C-24.

  • single output
  • output: 15W
  • output voltage tolerance: ±1%
  • maximal ripple and noise: 60mVpp
  • withstand voltage: 4000V DC
  • operating temperature: -40 to +90°C
  • dimensions: 50,8x25,4x12mm
  • weight: 30g
MDS15A-05, Mean Well DC/DC converters, 15W, 2x1, for medical technology, MDS15 series

MDS15A-05

235223 MDS15A-05 MDS15A-05 4711287472515 Mean Well DC/DC converter series MDS15. Converter modules in a 2x1 inch DIL housing with 15W and an input voltage ratio of 2:1. These devices have a low leakage current of less than 5µA, do not require a minimum load and are protected against overload (auto recovery) as well as short circuit (continuous). They are suitable for direct PCB mounting as well as for medical applications (2xMOPP) and comply with IEC60601-1 and EN55011 class A. We offer the following types of this Mean Well series: MDS15A-05, MDS15A-12, MDS15A-15, MDS15A-24, MDS15B-12, MDS15B-15, MDS15B-24, MDS15C-05, MDS15C-12, MDS15C-15 and MDS15C-24. single output output: 15W output voltage tolerance: ±1% maximal ripple and noise: 60mVpp withstand voltage: 4000V DC operating temperature: -40 to +90°C dimensions: 50,8x25,4x12mm weight: 30g

Specifications

manufacturer
Manufacturer's name MDS15A-05
GTIN 4711287472515
Output voltage [V] 5
Input voltage range [V] 9...18
Efficiency [%] 85
Output current [mA] 3000
Data Sheet

Unit price

26,19 €

Volume discounts

Quantity Unit price
50 + 24,39 €

Stock: 8
Further delivery:
CW 22/2025
