LDDS-350HW

Mean Well DC/DC LED driver series LDDS-H

DC/DC step-down LED drivers in a plastic housing (UL94V-0) with a constant current output and a wide input voltage range. These devices have a remote ON/OFF control and are protected against overtemperature as well as short circuit. They are suitable for LED lightning applications and comply with EN55015. We offer the following types of this Mean Well series: LDDS-250HW, LDDS-300HW, LDDS-350HW, LDDS-500HW, LDDS-700HW and LDDS-1000HW.

  • output current tolerance: ±5%
  • operating temperature: -40 to +55°C
  • connection: stranded wires
  • cable length: 10cm
  • dimensions: 47x12x7mm
  • weight: 9,5g
LDDS-350HW, Mean Well DC/DC step-down LED drivers, LDDS-H series

LDDS-350HW

237690 LDDS-350HW LDDS-350HW 4711287480510 Mean Well DC/DC LED driver series LDDS-H. DC/DC step-down LED drivers in a plastic housing (UL94V-0) with a constant current output and a wide input voltage range. These devices have a remote ON/OFF control and are protected against overtemperature as well as short circuit. They are suitable for LED lightning applications and comply with EN55015. We offer the following types of this Mean Well series: LDDS-250HW, LDDS-300HW, LDDS-350HW, LDDS-500HW, LDDS-700HW and LDDS-1000HW. output current tolerance: ±5% operating temperature: -40 to +55°C connection: stranded wires cable length: 10cm dimensions: 47x12x7mm weight: 9,5g

Specifications

manufacturer
Manufacturer's name LDDS-350HW
GTIN 4711287480510
Input voltage range [V] 12...56
Efficiency [%] 95
Output current [A] 0,35
Ripple [mVp-p] 200
Output voltage range [V] 2...45
Data Sheet

Unit price

7,19 €

Volume discounts

Quantity Unit price
50 + 6,69 €

Stock: 6
Next incoming goods:
CW 18/2025
20 units

Further delivery:
CW 22/2025
