HLG-600H-24

Mean Well LED driver series HLG-600H

LED drivers in a metal case (IP67) with a constant current/constant voltage, a wide input range, 600W and a typical lifetime of more than 62.000 hours. These SELV compliant devices comply with EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 class C, EN61000-3-3 as well as EN61547 and are suitable for LED lighting applications. They are protected against short circuit, overload (auto recovery), overvoltage as well as overtemperature and have a built-in active PFC function. We offer the following types of this Mean Well series: HLG-600H-12, HLG-600H-15, HLG-600H-20, HLG-600H-24, HLG-600H-30, HLG-600H-36, HLG-600H-42, HLG-600H-48 and HLG-600H-54.

  • single output
  • output: 480 to 604,8W
  • input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
  • maximal input inrush current: 70A
  • maximal leakage current: <0,75mA
  • overcurrent protection: 95 to 108%
  • withstand voltage I/P-O/P: 3750V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 1500V AC
  • operating temperature: -40 to +90°C
  • weight: 3900g
HLG-600H-24, Mean Well LED drivers, 600W, IP67, CV and CC (mixed mode), fixed preset, HLG-600H series

HLG-600H-24

135858 HLG-600H-24 HLG-600H-24 4711287451770 Mean Well LED driver series HLG-600H. LED drivers in a metal case (IP67) with a constant current/constant voltage, a wide input range, 600W and a typical lifetime of more than 62.000 hours. These SELV compliant devices comply with EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 class C, EN61000-3-3 as well as EN61547 and are suitable for LED lighting applications. They are protected against short circuit, overload (auto recovery), overvoltage as well as overtemperature and have a built-in active PFC function. We offer the following types of this Mean Well series: HLG-600H-12, HLG-600H-15, HLG-600H-20, HLG-600H-24, HLG-600H-30, HLG-600H-36, HLG-600H-42, HLG-600H-48 and HLG-600H-54. single output output: 480 to 604,8W input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC maximal input inrush current: 70A maximal leakage current: &lt;0,75mA overcurrent protection: 95 to 108% withstand voltage I/P-O/P: 3750V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 1500V AC operating temperature: -40 to +90°C weight: 3900g

Specifications

manufacturer
Manufacturer's name HLG-600H-24
GTIN 4711287451770
Output voltage [V] 24
Efficiency [%] 95
Output current [A] 25
Output voltage tolerance: [%] 1
Output power [W] 600
Ripple [mVp-p] 150
Data Sheet

Unit price

176,89 €

Volume discounts

Quantity Unit price
50 + 173,19 €

Stock: 0
Next incoming goods:
CW 48/2024
18 units

Further delivery:
CW 11/2025
