HEP-1000-24CAN

Mean Well power supply series HEP-1000

Switching power supplies in an aluminium housing with 1000W, a CAN bus interface, a DC OK signal and a universal input. These devices have a built-in active PFC function, are suitable for harsh environments and are protected against overload, overtemperature, overvoltage as well as short circuit. They have a programmable output voltage/current and comply with EN62368-1 as well as EN55032 class B. We offer the following types of this Mean Well series: HEP-1000-24CAN, HEP-1000-48CAN and HEP-1000-100CAN.

  • single output
  • output: 1000 to 1008W
  • input voltage: 90 to 305V AC (47 to 63Hz), 250 to 431V DC
  • maximal input inrush current: 40A
  • input current: 5,3A
  • leakage current: 0,75mA
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 1250V AC
  • operating temperature: -40 to +70°C
  • weight: 4000g
HEP-1000-24CAN, Mean Well switching power supplies, 1000W, for harsh environments, CAN bus, HEP-1000 series

HEP-1000-24CAN

244463 HEP-1000-24CAN HEP-1000-24CAN Mean Well power supply series HEP-1000. Switching power supplies in an aluminium housing with 1000W, a CAN bus interface, a DC OK signal and a universal input. These devices have a built-in active PFC function, are suitable for harsh environments and are protected against overload, overtemperature, overvoltage as well as short circuit. They have a programmable output voltage/current and comply with EN62368-1 as well as EN55032 class B. We offer the following types of this Mean Well series: HEP-1000-24CAN, HEP-1000-48CAN and HEP-1000-100CAN. single output output: 1000 to 1008W input voltage: 90 to 305V AC (47 to 63Hz), 250 to 431V DC maximal input inrush current: 40A input current: 5,3A leakage current: 0,75mA withstand voltage I/P-O/P: 3000V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 1250V AC operating temperature: -40 to +70°C weight: 4000g

Specifications

manufacturer
Manufacturer's name HEP-1000-24CAN
Output voltage [V] 24
Efficiency [%] 95
Output current [A] 42
Output voltage tolerance: [%] 1
Output power [W] 1008
Output voltage adjustment [V] 24...30
Ripple [mVp-p] 200
Data Sheet

Unit price

425,29 €

Stock: 0
Further delivery:
CW 12/2025

Minimum order quantity 200 units or
multiples of 200.
