GSV30E24-P1J

Mean Well LED power supply series GSV30E

LED plug-in switching power supplies with a universal input, 30W, a Europlug and protection class II. These devices are protected against overload (auto recovery), overvoltage as well as short circuit and comply with EN61347-1 as well as EN61347-2-13. They have a built-in active PFC function and are suitable for LED lighting applications. We offer the following types of this Mean Well series: GSV30E12-P1J, GSV30E24-P1J and GSV30E48-P1J.

  • single output
  • output: 30W
  • input voltage: 180 to 264V AC (47 to 63Hz), 255 to 373V DC
  • maximal input inrush current: 20A
  • no-load power: <0,5W
  • withstand voltage I/P-O/P: 3750V AC
  • operating temperature: -20 to +50°C
  • dimensions: 75,5x32x47,5mm
  • weight: 200g
GSV30E24-P1J, Mean Well LED plug-in drivers, 30W, constant voltage, with Europlug, GSV30E series

GSV30E24-P1J

241237 GSV30E24-P1J GSV30E24-P1J 4711287484013 Mean Well LED power supply series GSV30E. LED plug-in switching power supplies with a universal input, 30W, a Europlug and protection class II. These devices are protected against overload (auto recovery), overvoltage as well as short circuit and comply with EN61347-1 as well as EN61347-2-13. They have a built-in active PFC function and are suitable for LED lighting applications. We offer the following types of this Mean Well series: GSV30E12-P1J, GSV30E24-P1J and GSV30E48-P1J. single output output: 30W input voltage: 180 to 264V AC (47 to 63Hz), 255 to 373V DC maximal input inrush current: 20A no-load power: &lt;0,5W withstand voltage I/P-O/P: 3750V AC operating temperature: -20 to +50°C dimensions: 75,5x32x47,5mm weight: 200g

Specifications

manufacturer
Manufacturer's name GSV30E24-P1J
GTIN 4711287484013
Output voltage [V] 24
Efficiency [%] 86
Output current range [A] 0...1,25
Output voltage tolerance: [%] 2
Output power [W] 30
Ripple [mVp-p] 3500
Data Sheet
