ELG-75-C1050A-3Y

Mean Well LED driver series ELG-75-C

LED drivers in a metal housing (IP65) with a constant current, a protective earth conductor (PE) and 75W. These devices are suitable for LED lighting applications and their output current is adjustable through a built-in potentiometer on the bottom side of the case. They are protected against short circuit, overload (auto recovery), overvoltage as well as overtemperature and have a built-in active PFC function. We offer the following types of this Mean Well series: ELG-75-C350A-3Y, ELG-75-C500A-3Y, ELG-75-C700A-3Y, ELG-75-C1050A-3Y and ELG-75-C1400A-3Y.

  • single output
  • output: 74,55 to 75,6W
  • input voltage: 100 to 305V AC (47 to 63Hz), 142 to 431V DC
  • maximal input inrush current: 50A
  • withstand voltage I/P-O/P: 3750V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 1500V AC
  • operating temperature: -40 to +85°C
  • weight: 800g
ELG-75-C350A-3Y, Mean Well LED power supplies, 75W, IP65, constant current, with protective conductor PE, ELG-75-C series

ELG-75-C1050A-3Y

123297 ELG-75-C1050A-3Y ELG-75-C1050A-3Y 4711287481388 Mean Well LED driver series ELG-75-C. LED drivers in a metal housing (IP65) with a constant current, a protective earth conductor (PE) and 75W. These devices are suitable for LED lighting applications and their output current is adjustable through a built-in potentiometer on the bottom side of the case. They are protected against short circuit, overload (auto recovery), overvoltage as well as overtemperature and have a built-in active PFC function. We offer the following types of this Mean Well series: ELG-75-C350A-3Y, ELG-75-C500A-3Y, ELG-75-C700A-3Y, ELG-75-C1050A-3Y and ELG-75-C1400A-3Y. single output output: 74,55 to 75,6W input voltage: 100 to 305V AC (47 to 63Hz), 142 to 431V DC maximal input inrush current: 50A withstand voltage I/P-O/P: 3750V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 1500V AC operating temperature: -40 to +85°C weight: 800g

Specifications

manufacturer
Manufacturer's name ELG-75-C1050A-3Y
GTIN 4711287481388
Output current tolerance [%] 5
Efficiency [%] 90
Output power [W] 74,55
Output current [mA] 1050
Output voltage range [V] 35...71
Data Sheet

Unit price

30,19 €

Volume discounts

Quantity Unit price
50 + 28,39 €

Stock: 25
Further delivery:
CW 16/2025
