DRS-480-48

Mean Well battery charger series DRS-480

Switching power supplies in a DIN rail housing with 480W, a universal input, a MODBus interface and relay contacts / LED indicators for AC fail, battery low, charger fail as well as DC OK. These devices have a 2- or 3-stage charging curve (selectable through a DIL switch) and are protected against overload, deep discharge, voltage reversal, short circuit as well as overvoltage. They have a UPS function (with a battery charger) and comply with EN62368-1, EN55032 class B as well as EN61000-3-2. We offer the following types of this Mean Well series: DRS-480-24, DRS-480-36 and DRS-480-48.

  • output: 480W
  • input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
  • input current: 2,7A
  • maximal input inrush current: 60A
  • withstand voltage I/P-O/P: 4000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 1500V AC
  • operating temperature: -30 to +70°C
  • weight: 1650g
DRS-480-48, Mean Well DIN rail battery chargers, 480W, UPS function, DRS-480 series

DRS-480-48

241573 DRS-480-48 DRS-480-48 4711287485027 Mean Well battery charger series DRS-480. Switching power supplies in a DIN rail housing with 480W, a universal input, a MODBus interface and relay contacts / LED indicators for AC fail, battery low, charger fail as well as DC OK. These devices have a 2- or 3-stage charging curve (selectable through a DIL switch) and are protected against overload, deep discharge, voltage reversal, short circuit as well as overvoltage. They have a UPS function (with a battery charger) and comply with EN62368-1, EN55032 class B as well as EN61000-3-2. We offer the following types of this Mean Well series: DRS-480-24, DRS-480-36 and DRS-480-48. output: 480W input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC input current: 2,7A maximal input inrush current: 60A withstand voltage I/P-O/P: 4000V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 1500V AC operating temperature: -30 to +70°C weight: 1650g

Specifications

manufacturer
Manufacturer's name DRS-480-48
GTIN 4711287485027
Output voltage [V] 48
Efficiency [%] 93,5
Output current range [A] 0...10
Output voltage tolerance: [%] 1
Output power [W] 480
Ripple [mVp-p] 480
Data Sheet

Unit price

205,49 €

Volume discounts

Quantity Unit price
50 + 201,99 €

Stock: 71
Further delivery:
CW 12/2025
