DRC-100A

Mean Well battery charger series DRC-100

Switching power supplies in a DIN rail housing with 96,6W, a battery charger, a battery low protection, a battery low signal, a universal input, a power fail signal and screw terminals (touch guard). These devices have a UPS function and are protected against overload (auto recovery), voltage reversal (by fuse), overvoltage as well as short circuit. They have a fanless design and comply with UL/EN62368-1, EN55032 class B, EN61000-3-2 as well as EN61000-3-3. We offer the following types of this Mean Well series: DRC-100A and DRC-100B.

  • single output
  • output: 96,6W
  • input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC
  • maximal input inrush current: 60A
  • overload protection: 105 to 150%
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 500V AC
  • operating temperature: -30 to +70°C
  • weight: 370g
DRC-100A

DRC-100A

45565 DRC-100A DRC-100A 4711232760247 Mean Well battery charger series DRC-100. Switching power supplies in a DIN rail housing with 96,6W, a battery charger, a battery low protection, a battery low signal, a universal input, a power fail signal and screw terminals (touch guard). These devices have a UPS function and are protected against overload (auto recovery), voltage reversal (by fuse), overvoltage as well as short circuit. They have a fanless design and comply with UL/EN62368-1, EN55032 class B, EN61000-3-2 as well as EN61000-3-3. We offer the following types of this Mean Well series: DRC-100A and DRC-100B. single output output: 96,6W input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC maximal input inrush current: 60A overload protection: 105 to 150% withstand voltage I/P-O/P: 3000V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 500V AC operating temperature: -30 to +70°C weight: 370g

Specifications

manufacturer
Manufacturer's name DRC-100A
GTIN 4711232760247
Output voltage [V] 13,8
Efficiency [%] 87
Output current range [A] 4,5 (2,5)
Output voltage tolerance: [%] 1
Output power [W] 96,6
Output voltage adjustment [V] 12...15
Ripple [mVp-p] 120
Data Sheet

Unit price

39,59 €

Volume discounts

Quantity Unit price
50 + 38,29 €

Stock: 455
Next incoming goods:
CW 49/2024
240 units

Further delivery:
CW 12/2025
