DHP-1UT-A

Mean Well rack system series DHP-1U

Rack Power System with 3200 to 12800W, a PMBus protocol and a programmable output voltage/current. These devices allow parallel connection of up to 4 DRP-/DBR-3200 power supplies and comply with EN62368-1, EN55032 Class A/B as well as EN61000-3-2/3. They have a hot-swap function and a universal input. We offer the type DHP-1UT-A of this Mean Well series.

  • single output
  • output: 3192 to 12864W
  • input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC
  • leakage current: <1,5mA
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 700V AC
  • operating temperature: -30 to +70°C
  • weight: 4850g
DHP-1UT-A, Mean Well rack system, 3200 to 12800W, rack power, 19, DHP-1U series

DHP-1UT-A

111885 DHP-1UT-A DHP-1UT-A 4711232761459 Mean Well rack system series DHP-1U. Rack Power System with 3200 to 12800W, a PMBus protocol and a programmable output voltage/current. These&nbsp;devices&nbsp;allow parallel connection of up to 4 DRP-/DBR-3200 power supplies and comply with EN62368-1, EN55032 Class A/B as well as EN61000-3-2/3. They have a hot-swap function and a universal input. We offer the type DHP-1UT-A of this Mean Well series. single output output: 3192 to 12864W input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC leakage current: &lt;1,5mA withstand voltage I/P-O/P: 3000V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG:&nbsp;700V&nbsp;AC operating temperature: -30 to +70&deg;C weight:&nbsp;4850g

Specifications

manufacturer
Manufacturer's name DHP-1UT-A
GTIN 4711232761459
Data Sheet

Unit price

529,99 €

Stock: 16
Further delivery:
CW 12/2025
