DETN01N-05

Mean Well DC/DC converter series DETN01

Unregulated DC/DC converters in an SMD housing with 1W. These low-cost devices are suitable for direct PCB mounting and are protected against short circuit. They have a high efficiency (up to 83%) and comply with EN55032 class B. We offer the following types of this Mean Well series: DETN01L-05, DETN01L-12, DETN01L-15, DETN01M-05, DETN01M-12, DETN01M-15, DETN01N-05, DETN01N-12 and DETN01N-15.

  • dual output
  • output: 1W
  • output voltage tolerance: ±2%
  • maximal ripple and noise: 75mVpp
  • withstand voltage: 3000V DC
  • operating temperature: -40 to +90°C
  • weight: 1,2g
DETN01N-05, Mean Well DC/DC converters, 1W, SMD, DETN01 series

DETN01N-05

110475 DETN01N-05 DETN01N-05 4711287471037 Mean Well DC/DC converter series DETN01. Unregulated DC/DC converters in an SMD housing with 1W. These low-cost devices are suitable for direct PCB mounting and are protected against short circuit. They have a high efficiency (up to 83%) and comply with EN55032 class B. We offer the following types of this Mean Well series: DETN01L-05, DETN01L-12, DETN01L-15, DETN01M-05, DETN01M-12, DETN01M-15, DETN01N-05, DETN01N-12 and DETN01N-15. dual output output: 1W output voltage tolerance: ±2% maximal ripple and noise: 75mVpp withstand voltage: 3000V DC operating temperature: -40 to +90°C weight: 1,2g

Specifications

manufacturer
Manufacturer's name DETN01N-05
GTIN 4711287471037
Input voltage [V] 21,6...26,4
Output voltage [V] ±5
Efficiency [%] 76
Output current range [A] ±10...100
Data Sheet

Unit price

4,99 €

Volume discounts

Quantity Unit price
50 + 4,49 €

Stock: 36
Further delivery:
CW 23/2025
