DDRH-240-32

Mean Well DC/DC converter series DDRH-240

DC/DC converters in a DIN rail housing (TS-35/7.5 or 15) with a built-in EMI filter and a trimming output (±10%). These devices have a fanless design and are protected against overload, overvoltage, overtemperature as well as short circuit. They have a width of only 85,5mm and comply with IEC 62109-1, EN 62109-1 as well as EN55032 Klasse A. We offer the following types of this Mean Well series: DDRH-240-12, DDRH-240-24, DDRH-240-32 und DDRH-240-48.

  • single output
  • output: 200,4 to 240W
  • withstand voltage I/P-O/P: 4000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 2000V AC
  • operating temperature: -40 to +80°C
  • weight: 960g
DDRH-240-32, Mean Well DC/DC converters, 240W, DIN rail housing, DDRH-240 series

DDRH-240-32

242705 DDRH-240-32 DDRH-240-32 4711287486871 Mean Well DC/DC converter series DDRH-240. DC/DC converters in a DIN rail housing (TS-35/7.5 or 15) with a built-in EMI filter and a trimming output (±10%). These devices have a fanless design and are protected against overload, overvoltage, overtemperature as well as short circuit. They have a width of only 85,5mm and comply with IEC 62109-1, EN 62109-1 as well as EN55032 Klasse A. We offer the following types of this Mean Well series: DDRH-240-12, DDRH-240-24, DDRH-240-32 und DDRH-240-48. single output output: 200,4 to 240W withstand voltage I/P-O/P: 4000V AC withstand voltage I/P-FG: 2000V AC withstand voltage O/P-FG: 2000V AC operating temperature: -40 to +80°C weight: 960g

Specifications

manufacturer
Manufacturer's name DDRH-240-32
GTIN 4711287486871
Output voltage [V] 32
Efficiency [%] 86
Output current range [A] 0...7,5
Output voltage tolerance: [%] 1
Ripple [mVp-p] 240
Output voltage adjustment [V] 30...36
Input voltage [V DC] 250...1500
Data Sheet

Unit price

71,89 €

Volume discounts

Quantity Unit price
50 + 70,39 €

Stock: 7
Further delivery:
CW 09/2025
