> Passive elements>Capacitors>Electrostatic double-layer capacitors (EDLCs)>Kemet SuperCaps, FG series>FG0H224ZF

Manufacturers

FG0H224ZF

Kemet double-layer capacitor series FG

  • lead-free electrostatic double-layer capacitors (EDLCs)
  • with a high reliability against liquid leakage
  • maintenance free type
  • maximal soldering temperature: 245°C/5s
  • operating temperature: -25 to +70°C
  • capacitance tolerance: -20/+80%
  • bulk
FG0H224ZF, Kemet SuperCaps, FG series

FG0H224ZF

236669 FG0H224ZF FG0H224ZF Kemet double-layer capacitor series FG. lead-free electrostatic double-layer capacitors (EDLCs) with a high reliability against liquid leakage maintenance free type maximal soldering temperature: 245°C/5s operating temperature: -25 to +70°C capacitance tolerance: -20/+80% bulk

Specifications

manufacturer
Manufacturer's name FG0H224ZF
Rated current [mA] 0,33
Max. operating voltage [V DC] 5,5
Capacity [F] charge 0,22...
Equivalent series resistance, max. [Ω] 100
Pitch [mm] 5,08
Dimensions [mm] 13x9
Data Sheet

Unit price

1,33 €

Stock: 0
Further delivery:
CW 24/2025

Minimum order quantity 800 units or
multiples of 800.
