HNP-MOD2412

HN-Power switching power supplies series HNP-MOD24

These switching power supplies in a round plastic case are protected against overload and short circuit. They conform with protection class II, IP67, EN55032, and EN62368-1. We offer the following types of this HN-Power series: HNP-MOD2412 and HNP-MOD2424.

  • power output: 24W
  • input voltage range: 90 to 264V AC
  • input current: 0,6A
  • isolation voltage (I/P-O/P): 3000V
  • conection terminal: strand
  • operating temperature: -10 to +40°C
  • dimensions: 60x61,5x30mm
  • weight: 160g
HNP-MOD2412, HN-Power switching power supplies, 24W, plastic case, HNP-MOD24 series

HNP-MOD2412

247304 HNP-MOD2412 HNP-MOD2412 HN-Power switching power supplies series HNP-MOD24. These switching power supplies in a round plastic case are protected against overload and short circuit. They conform with protection class II, IP67, EN55032, and EN62368-1. We offer the following types of this HN-Power series: HNP-MOD2412 and HNP-MOD2424. power output: 24W input voltage range: 90 to 264V AC input current: 0,6A isolation voltage (I/P-O/P): 3000V conection terminal: strand operating temperature: -10 to +40°C dimensions: 60x61,5x30mm weight: 160g

Specifications

manufacturer
Manufacturer's name HNP-MOD2412
Output voltage [V] 12
Efficiency [%] 84
Output current [A] 2
Output power [W] 12
Ripple [mVp-p] 200
Data Sheet

Unit price

10,39 €

Stock: 7
