BV EI 302 2902

Hahn PCB transformers

Transformers with an EI30 core with 1VA. These devices are short circuit proof and comply with temperature resistance class Ta 70/F. They are vacuum casted and suitable for PCB mounting. We offer the following types of this Hahn series: BV EI 302 2902 and BV EI 302 2810.

  • core: EI 30
  • output: 1VA
  • input voltage: 230V (50/60Hz)
  • temperature class: Ta 70/F
  • end temperature (short circuit): 190°C
  • end temperature: 140°C
  • permissible overtemperature: 70K
BV EI 302

BV EI 302 2902

111646 BV EI 302 2902 BVEI3022902 BVEI3022902 Hahn PCB transformers. Transformers with an EI30 core with 1VA. These devices are short circuit proof and comply with temperature resistance class Ta 70/F. They are vacuum casted and suitable for PCB mounting. We offer the following types of this Hahn series: BV EI 302 2902 and BV EI 302 2810. core: EI 30 output: 1VA input voltage: 230V (50/60Hz) temperature class: Ta 70/F end temperature (short circuit): 190°C end temperature: 140°C permissible overtemperature: 70K

Specifications

manufacturer
Manufacturer's name BVEI3022902
Secondary voltage [V] 9
Secondary current [A] 0,111

Unit price

8,89 €

Stock: 19
Next incoming goods:
CW 48/2024
50 units

Further delivery:
CW 50/2024

Minimum order quantity 1 to 4 units or multiples of 5 plus 0 to 4 .
