> Passive elements>Transformers>Flyback converters>Hahn flyback converters, for Tiny Switch switching regulators, EE 16/5>V 50111

Manufacturers

V 50111

flyback converters

• the converter uses the principle of energy storage to transfer voltage from the input to the output in power transformer technology for this TinySwitch® series
• construction according to EN 61 558, EN 60 950


• creeping distance min. 8 mm
• UL listed materials
• insulation material class E
• two outputs for connection in parallel or in series

Series V 501_

V 50111

35386 V 50111 V50111 V50111 flyback converters. • the converter uses the principle of energy storage to transfer voltage from the input to the output in power transformer technology for this TinySwitch® series• construction according to EN 61 558, EN 60 950 • creeping distance min. 8 mm• UL listed materials• insulation material class E• two outputs for connection in parallel or in series

Specifications

manufacturer
Manufacturer's name V50111
Primary voltage [V] 85...265
Power [VA] 7
Secondary voltage [V] 2x9
Secondary current [A] 2x0,390
Data Sheet

Unit price

2,19 €

Stock: 188
Further delivery:
CW 07/2025

Minimum order quantity 4 units or
multiples of 4.
