> Passive elements>Capacitors>Electrolytic capacitors>FTCAP electrolytic capacitors, radial, soldering lugs, clamp mounting, 85°C, LFA series>LFA 100 V 1000 µF

Manufacturers

LFA 100 V 1000 µF

Electrolytic capacitors series LFA by Fischer & Tausche

These capacitors are endued with soldering lug and mounting clamps. We are offering the following types by Fischer & Tausche: LFA 63 V 1000 µF, LFA 63V 2200 µF, LFA 63 V 4700 µF, LFA 63 V 6800 µF, LFA 63 V 10000 µF, LFA 100 V 1000 µF, LFA 100 V 2200 µF, LFA 100 V 4700 µF, LFA 100 V 10000 µF, LFA 350 V 220 µF, LFA 350 V 330 µF and LFA 350 V 470 µF.

* lose
* tolerance: 20%
* temperature range: -40 to +85°C

LFA10210035050, radial, with lugs and clamp mounted, 85°C

LFA 100 V 1000 µF

109759 LFA 100 V 1000 µF LFA10210035050 LFA10210035050 Electrolytic capacitors series LFA by Fischer & Tausche. These capacitors are endued with soldering lug and mounting clamps. We are offering the following types by Fischer & Tausche: LFA 63 V 1000 µF, LFA 63V 2200 µF, LFA 63 V 4700 µF, LFA 63 V 6800 µF, LFA 63 V 10000 µF, LFA 100 V 1000 µF, LFA 100 V 2200 µF, LFA 100 V 4700 µF, LFA 100 V 10000 µF, LFA 350 V 220 µF, LFA 350 V 330 µF and LFA 350 V 470 µF. * lose* tolerance: 20%* temperature range: -40 to +85°C

Specifications

manufacturer
Manufacturer's name LFA10210035050
Nominal voltage [V DC] 100
Reverse current [A] 1,9
Impedance [Ω] 127
Rated capacitance [µF] 1000
Loss factor at 100Hz, 20°C [%] 10
D x L [mm] 35x50
Data Sheet

Unit price

16,89 €

Stock: 0
Further delivery:
CW 08/2025

Minimum order quantity 60 units or
multiples of 60.
