> Passive elements>Relays>Electromechanical relays>Finder industrial relays, 10A, 3 changeover contacts, 36,4x32,5x51mm, 60 series>60.13 230V AC

Manufacturers

60.13 230V AC

rated current: 10A

• lockable test button with mechanical flag indicator
• relays protection class RTI
• contact: 3PDT
• contact material: AgNi
• rated current: 10A
• max. switching current: 20A
• max. switching voltage: 400V AC
• max. switching power: 2500VA
• operate/release time: 9/9ms
• testing voltage
coil/contact: 3600V
opening contact: 1000V
• lifetime
mechanical (AC/DC): 20x106 / 50x106 cycles
electrical: 200x103 cycles
• operating temperature: -40...+70°C

Finder 60.13 series

60.13 230V AC

11898 60.13 230V AC 60.13.8.230.0040 60.13.8.230.0040 rated current: 10A. • lockable test button with mechanical flag indicator• relays protection class RTI• contact: 3PDT• contact material: AgNi• rated current: 10A• max. switching current: 20A• max. switching voltage: 400V AC• max. switching power: 2500VA• operate/release time: 9/9ms• testing voltagecoil/contact: 3600Vopening contact: 1000V• lifetimemechanical (AC/DC): 20x106 / 50x106 cycleselectrical: 200x103 cycles• operating temperature: -40...+70°C

Specifications

manufacturer
Manufacturer's name 60.13.8.230.0040
Rated current [mA] 10,5
Switch positions 3 changeover...
Nominal voltage [V] 230V AC
Nominal resistance [Ω] 7250
Switching current [A] 10
Response voltage [V] 184...253
Max. switching power [VA] 2500
Data Sheet

Unit price

13,09 €

Stock: 18
Next incoming goods:
CW 49/2024
10 units

Further delivery:
CW 10/2025

Minimum order quantity 1 to 3 units or multiples of 5 plus 0 to 3 .
