> Passive elements>NTCs/PTCs/varistors>Varistors>Epcos metal oxide varistors, pitch 5/7,5mm, SIOV series>S 10 K 50

Manufacturers

S 10 K 50

Epcos metal oxide varistor series SIOV

  • wired and round varistor elements
  • with an epoxy resin coating (UL94V-0)
  • operating temperature: -40 to +85°C
  • pitch: 5 resp. 7,5mm
  • bulk
S 10 K

S 10 K 50

45353 S 10 K 50 B72210S0500K101 B72210S0500K101 Epcos metal oxide varistor series SIOV. wired and round varistor elements with an epoxy resin coating (UL94V-0) operating temperature: -40 to +85°C pitch: 5 resp. 7,5mm bulk

Specifications

manufacturer
Manufacturer's name B72210S0500K101
Current [A] 2500
A [mm] 1,4
(Max.) RMS voltage [V] 50
Operating voltage [V] 65
Varistor voltage at 1mA [V] 82
Supply voltage [V] 135
E [mm] 7,5
Tolerance of varistor voltage [%] ±10
Capacity [pF] 950
Material strength [mm] 3,9
B [mm] 12
L1 [mm] 25
H [mm] 14,5
D [mm] 0,8
Data Sheet

Unit price

0,108 €

Stock: 560
Next incoming goods:
CW 04/2025
1000 units

Further delivery:
CW 11/2025

Minimum order quantity 1 to 10 units or multiples of 25 plus 0 to 10 .
