EA10442G2401

EDACPOWER desktop power supply series EA1044

Desktop switching power supplies with 40W, a universal input and class II protection. These devices are suitable for indoor applications and are protected against short circuit, overload (auto recovery) as well as overvoltage. They comply with UL/EN 62368-1, EN55032 class B and energy efficiency Level VI (DoE). We offer the following types of this EDACPOWER series: EA10442D1201, EA10442D1501 and EA10442G2401.

  • single output
  • output: 40W
  • input voltage: 100 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 140A
  • cable length: 1,2m
  • input plug: C8
  • output plug, coax: 2,1x5,5mm
  • dimensions: 85,5x35,7x25,7mm
  • operating temperature: 0 to +40°C
  • weight: 160g
EA10442G(T01), EDACPOWER external switching power supplies, 40W, energy efficiency Level VI, EA1044 series

EA10442G2401

233989 EA10442G2401 EA10442G(T01) EA10442G(T01) EDACPOWER desktop power supply series EA1044. Desktop switching power supplies with 40W, a universal input and class II protection. These devices are suitable for indoor applications and are protected against short circuit, overload (auto recovery) as well as overvoltage. They comply with UL/EN 62368-1, EN55032 class B and energy efficiency Level VI (DoE). We offer the following types of this EDACPOWER series: EA10442D1201, EA10442D1501 and EA10442G2401. single output output: 40W input voltage: 100 to 264V AC (47 to 63Hz) maximal input inrush current: 140A cable length: 1,2m input plug: C8 output plug, coax: 2,1x5,5mm dimensions: 85,5x35,7x25,7mm operating temperature: 0 to +40°C weight: 160g

Specifications

manufacturer
Manufacturer's name EA10442G(T01)
Output voltage [V] 24
Efficiency [%] 88,58
Output current [A] 1,66
Output voltage tolerance: [%] +5/-5
Output power [W] 40
Ripple [mVp-p] 250
Data Sheet

Unit price

10,69 €

Volume discounts

Quantity Unit price
100 + 9,79 €
50 + 10,09 €

Stock: 354
Further delivery:
CW 18/2025
