ESP4020

SMD slide switches ESP30/40 by ECE

* pitch 2.54mm
* all plastic parts flame-resistant in accordance with UL94V-0
* reflow soldering
* by ECE
* switching capacity: 0,5A, 12V DC/1mA, 10mV, Min.
* contact resistance, max.: 30mΩ
* dielectric strength: 2mA, 500V DC/1min.
* capacitance, max.: 1,5pF
* insulation resistance (500V DC): 10000MΩ/1min.
* operations: 10000
* operating temperature: -25...+70°C
* soldering temperature: 240°C/20s
* soldering temperature, max.: 260°C
* vibration test: normal operation 10...60Hz, 1.5mm movement
* corrosion test (salt solution): 35°C, 5%/24h
ESP4020 by ECE

ESP4020

39601 ESP4020 ESP4020 SMD slide switches ESP30/40 by ECE. * pitch 2.54mm* all plastic parts flame-resistant in accordance with UL94V-0* reflow soldering* by ECE* switching capacity: 0,5A, 12V DC/1mA, 10mV, Min.* contact resistance, max.: 30mΩ* dielectric strength: 2mA, 500V DC/1min.* capacitance, max.: 1,5pF* insulation resistance (500V DC): 10000MΩ/1min.* operations: 10000* operating temperature: -25...+70°C* soldering temperature: 240°C/20s* soldering temperature, max.: 260°C* vibration test: normal operation 10...60Hz, 1.5mm movement* corrosion test (salt solution): 35°C, 5%/24h

Specifications

manufacturer
Manufacturer's name ESP4020
Switch positions SPDT
Switching current [A] 0,5
Data Sheet

Unit price

0,364 €

Stock: 1378
Further delivery:
CW 09/2025

Minimum order quantity 53 units or
multiples of 53.
