K 70 1 Liter

The electric isolation of PCBs is at risk due to moisture, industrial dust particals or corrosive atmosphere. The CRC PCB lacquer contains high leakage current and dielectric strength and is used for the protection of PCBs.

acryl lacquer, transparent K70
* universal insulating lacquer for multiple use
* quick drying, colourless transparent, flexible, UV light resistant
* protects PCBs and surfaces against humid anorganic-acid or caustic vapours
* low viscosity, solvent drying acrylic based lacquer
* drying time at 20°C: 15...20 mins.
* durable adhesion in temperature ranges between -40...+ 60°C, short period temperature capacity at 100°C (max. 0,5h)
* dielectric strength >80kV/mm
* directly solderable for repair purposes


1035381, CRC Kontakt Chemie protective coating for PCBs

K 70 1 Liter

245326 K 70 1 Liter 1035381 1035381 The electric isolation of PCBs is at risk due to moisture, industrial dust particals or corrosive atmosphere. The CRC PCB lacquer contains high leakage current and dielectric strength and is used for the protection of PCBs.acryl lacquer, transparent K70* universal insulating lacquer for multiple use* quick drying, colourless transparent, flexible, UV light resistant* protects PCBs and surfaces against humid anorganic-acid or caustic vapours* low viscosity, solvent drying acrylic based lacquer* drying time at 20°C: 15...20 mins.* durable adhesion in temperature ranges between -40...+ 60°C, short period temperature capacity at 100°C (max. 0,5h)* dielectric strength >80kV/mm* directly solderable for repair purposes

Specifications

manufacturer
Manufacturer's name 1035381
Data Sheet

Unit price

28,29 €

Stock: 6
Further delivery:
CW 04/2025
