SL 32 P

male connectors, angled, SL_P by Conec

• DIN 41612
• type: C
• pitch: 5.08mm
• series: SL_P
• by Conec
• angled solder pins
• insulation shell: glass filled polyamide (PBT), (UL94V-0)
• contact material: copper alloy
• contact surface (class 3): hard gold
• mating and withdraw force
32-pole: <30N

• air and creepage: >1.2mm
• operating voltage: 250V AC
• test voltage Ueff (contact/contact): 1kV
• operating current at ambient temperature
+20°C: 2A
+70°C: 1A
+100°C: 0.5A
• contact resistance: <20mΩ
• insulation resistance: >1011Ω
• temperature range: -55...+125°C
• class: 3 = 50 cycles

SL 32 P

SL 32 P

11844 SL 32 P 121A10119X 121A10119X male connectors, angled, SL_P by Conec. • DIN 41612• type: C• pitch: 5.08mm• series: SL_P• by Conec• angled solder pins• insulation shell: glass filled polyamide (PBT), (UL94V-0)• contact material: copper alloy• contact surface (class 3): hard gold• mating and withdraw force32-pole: &lt;30N • air and creepage: &gt;1.2mm• operating voltage: 250V AC• test voltage Ueff (contact/contact): 1kV• operating current at ambient temperature+20°C: 2A+70°C: 1A+100°C: 0.5A• contact resistance: &lt;20mΩ• insulation resistance: &gt;1011Ω• temperature range: -55...+125°C• class: 3 = 50 cycles

Discontinued items. Only remainder of stock available.

Specifications

manufacturer
Manufacturer's name 121A10119X
Number of poles 32
Equipping a + c
Pitch [mm] 5,08
Data Sheet

Unit price

1,22 €

Stock: 1
