ESB101.23(R2)

Camtec inrush current limiter series ESB001/ESB101(R2)/ESB201(R2)/ESB303(R2)/ESB00351(R2)

Single- (ESB101_/ESB201_) resp. three-phase (ESB303_) peak / RMS current limiters in a plastic housing (IP20/UL94V-0) for capacitive loads (1000µF to 10.000µF). These devices have an integrated bypass relay as well as a built-in temperature monitoring and comply with EN60950-1, EN61010-1, EN62368-1 as well as EN55032. We offer various types of this Camtec series.

ESB101.23(R2), Camtec inrush current limiters, ESB001/ESB101/ESB201/ESB303/ESB00351 series

ESB101.23(R2)

241036 ESB101.23(R2) ESB101.23(R2) Camtec inrush current limiter series ESB001/ESB101(R2)/ESB201(R2)/ESB303(R2)/ESB00351(R2). Single- (ESB101_/ESB201_) resp. three-phase (ESB303_) peak / RMS current limiters in a plastic housing (IP20/UL94V-0) for capacitive loads (1000µF to 10.000µF). These devices have an integrated bypass relay as well as a built-in temperature monitoring and comply with EN60950-1, EN61010-1, EN62368-1 as well as EN55032. We offer various types of this Camtec series.

Specifications

manufacturer
Manufacturer's name ESB101.23(R2)
R.M.S. current limiting, max. [A] 16,3
Limiting intervall, min. [ms] 900
Limiting time [ms] 300
Capacity [µF] 2000
Data Sheet

Unit price

64,89 €

Stock: 130
Next incoming goods:
CW 03/2025
40 units

Further delivery:
CW 05/2025
