ESB00351(R2)

Camtec inrush current limiter series ESB001/ESB101(R2)/ESB201(R2)/ESB303(R2)/ESB00351(R2)

Single- (ESB101_/ESB201_) resp. three-phase (ESB303_) peak / RMS current limiters in a plastic housing (IP20/UL94V-0) for capacitive loads (1000µF to 10.000µF). These devices have an integrated bypass relay as well as a built-in temperature monitoring and comply with EN60950-1, EN61010-1, EN62368-1 as well as EN55032. We offer various types of this Camtec series.

ESB00351(R2), Camtec inrush current limiters, ESB001/ESB101/ESB201/ESB303/ESB00351 series

ESB00351(R2)

241033 ESB00351(R2) ESB00351(R2) Camtec inrush current limiter series ESB001/ESB101(R2)/ESB201(R2)/ESB303(R2)/ESB00351(R2). Single- (ESB101_/ESB201_) resp. three-phase (ESB303_) peak / RMS current limiters in a plastic housing (IP20/UL94V-0) for capacitive loads (1000µF to 10.000µF). These devices have an integrated bypass relay as well as a built-in temperature monitoring and comply with EN60950-1, EN61010-1, EN62368-1 as well as EN55032. We offer various types of this Camtec series.

Specifications

manufacturer
Manufacturer's name ESB00351(R2)
R.M.S. current limiting, max. [A] 24,8
Limiting intervall, min. [ms] 900
Limiting time [ms] 150
Capacity [µF] 10.000
Data Sheet

Unit price

188,99 €

Stock: 18
Further delivery:
CW 05/2025
