IC 24 TH 13,824 MHz

Abundance quartz crystal series HC49/U-S

  • microprocessor quartz crystals in an HC 49/U-S housing
  • made of metal
  • suitable for through-hole mounting (THT)
  • aging: ±5ppm/year
  • shunt capacitance: 7pF
  • drive level: 1mW
  • operating temperature: -10 to +60°C
  • frequency: 3,579 to 25MHz
IC 24 TH 13,824 MHz

IC 24 TH 13,824 MHz

46049 IC 24 TH 13,824 MHz IC24013.824M30.0CE1B IC24013.824M30.0CE1B Abundance quartz crystal series HC49/U-S. microprocessor quartz crystals in an HC 49/U-S housing made of metal suitable for through-hole mounting (THT) aging: ±5ppm/year shunt capacitance: 7pF drive level: 1mW operating temperature: -10 to +60°C frequency: 3,579 to 25MHz

Specifications

manufacturer
Manufacturer's name IC24013.824M...
Case HC 49/U-S
Equivalent series resistance, max. [Ω] 40
Frequency [MHz] 13,824
Capacity [pF] 30
Data Sheet

Unit price

0,144 €

Stock: 0
Further delivery:
CW 04/2025

Minimum order quantity 500 units or
multiples of 500.
