Q 4,9152 MHz HC 49 U-S

Abundance quartz crystal series HC49/U-S

  • microprocessor quartz crystals in an HC 49/U-S housing
  • made of metal
  • suitable for through-hole mounting (THT)
  • aging: ±5ppm/year
  • shunt capacitance: 7pF
  • drive level: 1mW
  • operating temperature: -10 to +60°C resp. -40 to +85°C (automotive)
  • frequency: 3,579 to 25MHz
housing HC 49/U-S

Q 4,9152 MHz HC 49 U-S

3776 Q 4,9152 MHz HC 49 U-S 49S4H4.915200M-AF-3030150R-16R 49S4H4.915200M-AF-3030150R-16R Abundance quartz crystal series HC49/U-S. microprocessor quartz crystals in an HC 49/U-S housing made of metal suitable for through-hole mounting (THT) aging: ±5ppm/year shunt capacitance: 7pF drive level: 1mW operating temperature: -10 to +60°C resp. -40 to +85°C (automotive) frequency: 3,579 to 25MHz

Specifications

manufacturer
Manufacturer's name 49S4H4.91520...
Case HC 49/U-S
Operating temperature range [°C] -10...+60
Frequency [MHz] 4,9152
Data Sheet

Unit price

0,279 €

Stock: 2379
Further delivery:
CW 25/2025

Minimum order quantity 1 to 9 units or multiples of 10 plus 0 to 9 .
