Mean Well power supply series LOP-500

Open frame switching power supplies with 500W (forced air), an adjustable output voltage, a low no-load power, an auxiliary power output (12V/0,5A), protection class I/II and an extremely low leakage current. These devices are suitable for medical technology applications (2xMOPP), have a built-in active PFC function and are protected against overload, overtemperature, overvoltage as well as short circuit. They have a peak load capability of 150% and comply with EN60601-1, EN62368-1, EN60335-1, EN61558-1, EN61558-2-16, EN55032 class A/B as well as EN55014. We offer the following types of this Mean Well series: LOP-500-12, LOP-500-15, LOP-500-18, LOP-500-24, LOP-500-27, LOP-500-36, LOP-500-48 and LOP-500-54.

single output
output: 499,2 to 502,2W
input voltage: 80 to 264V AC (47 to 63Hz), 113 to 370V DC
maximal input inrush current: 80A
no-load power: <0,5W
withstand voltage I/P-O/P: 4000V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 1500V AC
operating temperature: -40 to +80°C
dimensions: 127x76,2x30,5mm
weight: 420g
