Mean Well LED driver series XLG-150

LED drivers in a metal housing (IP67) with 150W, a constant voltage/current (XLG-150-_), a constant power (XLG-150-L/M/H), a universal input and a low no-load power. These SELV compliant devices have a built-in ...

Mean Well LED driver series XLG-150

LED drivers in a metal housing (IP67) with 150W, a constant voltage/current (XLG-150-_), a constant power (XLG-150-L/M/H), a universal input and a low no-load power. These SELV compliant devices have a built-in active PFC function and are protected against overload (auto recovery), overcurrent, overvoltage, overtemperature as well as short circuit. They are suitable for LED lighting applications, are not dimmable and comply with EN61347-1, EN61347-2-13, EN623684, EN60335-1, EN55015, EN61000-3-2 class C as well as EN61547. We offer the following types of this Mean Well series: XLG-150-12, XLG-150-24, XLG-150-L, XLG-150-M and XLG-150-H.

  • single output
  • output: 150W
  • input voltage: 100 to 305V AC (47 to 63Hz), 142 to 431V DC
  • maximal input inrush current: 50A
  • no-load power: <0,5W
  • withstand voltage I/P-O/P: 4200V AC
  • withstand voltage I/P-FG: 2100V AC
  • withstand voltage O/P-FG: 1500V AC
  • dimensions: 180x63x35,5mm
  • weight: 800g
