Mean Well variable frequency drive series VFD-250P-230

Variable frequency drives in an enclosed 5"x3" housing with 250W and a peak load capability of up to 200%. These devices have a built-in active PFC function, can be controlled with an external...

Mean Well variable frequency drive series VFD-250P-230

Variable frequency drives in an enclosed 5"x3" housing with 250W and a peak load capability of up to 200%. These devices have a built-in active PFC function, can be controlled with an external PWM signal and are protected against short circuit. They are suitable for 3-phase motors, have a current sensor, a voltage sensor as well as a temperature sensor and comply with EN61800-5-1 as well as EN61800-3 class A. We offer the type VFD-250P-230 of this Mean Well series.

  • output: 250W
  • input voltage: 90 to 264V AC (47 to 63Hz)
  • maximal input inrush current: 70A
  • leakage current: <2mA
  • operating temperature: -30 to +70°C
  • dimensions: 127x76,2x35mm
  • weight: 0,26kg
> More
Data Sheet
Showing 1 - 1 of 1 product
  • Product Stock Unit price Volume discounts
  • Mean Well
    VFD-250P-230, Mean Well variable frequency drives, 250W, enclosed, VFD-250P-230 series
    37,29 €
    244427 VFD-250P-230 VFD-250P-230
    37,29 €
    Quantity Unit price
    50 + 37,29 €

    More
    Stock: 10
