Mean Well power supply series HRPG-1000N3

Switching power supplies in an enclosed housing with 1000W, a fan, a universal input, protection class I, a DC OK signal and a remote ON/OFF control. These devices have a built-in active PFC function, are ...

Mean Well power supply series HRPG-1000N3

Switching power supplies in an enclosed housing with 1000W, a fan, a universal input, protection class I, a DC OK signal and a remote ON/OFF control. These devices have a built-in active PFC function, are suitable for a peak power of up to 320% and are protected against overload, short circuit as well as overvoltage. They have a parallel function (3+1 units / max. 4000W), a low no-load power consumption (<0,85W) and comply with EN62368-1 as well as EN55032 class B. We offer the following types of this Mean Well series: HRPG-1000N3-12, HRPG-1000N3-24, HRPG-1000N3-36 and HRPG-1000N3-48.

  • single output
  • output: 960 to 1008W
  • input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC
  • maximal input inrush current: 40A
  • leakage current: <1,2mA
  • withstand voltage I/P-O/P: 3000V AC
  • withstand voltage I/P-FG: 2000V AC
  • withstand voltage O/P-FG: 500V AC
  • connection type: screw terminal
  • operating temperature: -40 to +70°C
  • weight: 1460g
> More
Data Sheet
Showing 1 - 4 of 4 products
  • Product Stock Unit price Volume discounts
  • Mean Well
    HRPG-1000N3-12, Mean Well switching power supplies, 1000W, 320% peak power, HRPG-1000N3 series
    179,19 €
    244394 HRPG-1000N3-12 HRPG-1000N3-12
    179,19 €
    Quantity Unit price
    50 + 176,19 €
    Stock: 8
  • Mean Well
    HRPG-1000N3-24, Mean Well switching power supplies, 1000W, 320% peak power, HRPG-1000N3 series
    179,19 €
    244395 HRPG-1000N3-24 HRPG-1000N3-24
    179,19 €
    Quantity Unit price
    50 + 176,19 €
    Stock: 25
  • Mean Well
    HRPG-1000N3-36, Mean Well switching power supplies, 1000W, 320% peak power, HRPG-1000N3 series
    179,19 €
    244396 HRPG-1000N3-36 HRPG-1000N3-36
    179,19 €
    Quantity Unit price
    50 + 176,19 €
    Stock: 8
  • Mean Well
    HRPG-1000N3-48, Mean Well switching power supplies, 1000W, 320% peak power, HRPG-1000N3 series
    179,19 €
    244397 HRPG-1000N3-48 HRPG-1000N3-48
    179,19 €
    Quantity Unit price
    50 + 176,19 €
    Stock: 1
Showing 1 - 4 of 4 products
