Mean Well DC/DC converter series DDRH-120

DC/DC converters in a DIN rail housing (TS-35/7,5/15) with 120W, a regulated output voltage, a DC OK relay contact and an input voltage ratio of 6:1. These devices have a width of only 63mm, a fanless design and are protected against overload, short circuit, DC input reverse polarity, overtemperature as well as overvoltage. They are suitable for an operating altitude of up to 5000m and comply with IEC62109-1, EN62109-1 as well as EN55032 class A. We offer the following types of this Mean Well series: DDRH-120-12, DDRH-120-24, DDRH-120-32 and DDRH-120-48.

single output
output: 100,8 to 120W
overload protection: 105 to 135%
withstand voltage I/P-O/P: 4000V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 2000V AC
operating temperature: -40 to +80°C
weight: 845g

> More

Data Sheet
