PTR Hartmann terminal block series AKZ350

These black terminal blocks in a lift principle are suitable for reflow and have a pitch of 5,08mm. They have a horizontal cable entry, a vertical screw direction, and a nominal current of 17,5A. These dev...

PTR Hartmann terminal block series AKZ350

These black terminal blocks in a lift principle are suitable for reflow and have a pitch of 5,08mm. They have a horizontal cable entry, a vertical screw direction, and a nominal current of 17,5A. These devices are available in as a single terminal block (AKZ350_V-BK-HT), as well as a single terminal block with a blister strap on wheels (AKZ350_V-BK-HT-G). We offer various types of this PTR Hartmann series.

  • nominal voltage: 250V AC
  • nominal current: 17,5A
  • over voltage category: III
  • test voltage: 2kV
  • pollution level: 3
  • nominal cross-section: 0,5 to 2,5mm^2 (single stranded), 0,5 to 1,5mm^2 (fine stranded)
  • isolation length: 6mm
  • isolation body: PPA
  • operating temperature: -40 to +105°C
  • inflammability class: UL94V-0
  • colour: black
