Citel surge protection device series DAC15CS

Type 3 surge protection devices (SPD) in a compact plastic housing (IP20) for protection class I applications. These devices are suitable for DIN rail mounting (35mm) and comply with IEC61643-11, EN6164...

Citel surge protection device series DAC15CS

Type 3 surge protection devices (SPD) in a compact plastic housing (IP20) for protection class I applications. These devices are suitable for DIN rail mounting (35mm) and comply with IEC61643-11, EN61643-11 as well as UL1449. We offer the following types of this Citel series: DAC15CS-11-275 and DAC15CS-31-275.

  • protected phases DAC15CS-11_: 1
  • protected phases DAC15CS-31_: 3
  • SPD: type 3
  • protection level: 1500V
  • protection class: I
  • leakage current: 15kA
  • connection type: screw terminal
  • additional protection: remote signaling contact
  • operating temperature: -40 to +85°C
> More
