Mean Well DC/AC converter series NTS-450

Inverters with 450W, a pure sine wave output (THD<3%), a remote ON/OFF control and an automatic shutdown in case of a deeply discharged battery. These devices have an adjustable output voltage and are protected against overvoltage, short circuit as well as overtemperature. They trigger an alarm in case of a low battery voltage and comply with IEC62368-1, EN62368-1 as well as EN55032 class A. We offer the following types of this Mean Well series: NTS-450-212EU, NTS-450-224EU and NTS-450-248EU.

output: 450W
selectable output voltage: 200/220/230/240V AC
output voltage tolerance: ±3%
output frequency: 50/60Hz
output frequency tolerance: ±0,1%
curve shape: pure sine wave, THD<3%
connection type: EU type F
operating temperature: -20 to +70°C
withstand voltage I/P-O/P: 3000V AC
withstand voltage O/P-FG: 1500V AC
dimensions: 210x130x55mm
weight: 1300g
