Mean Well DC/AC converter series NTS-300

Inverters with 300W, a pure sine wave output (THD<3%), a remote ON/OFF function as well as an alarm function in case of a low battery voltage. These devices have an adjustable output voltage and are protected against overtemperature, short circuit as well as overvoltage. They switch off automatically in case of a deeply discharged battery and comply with IEC62368-1, EN62368-1 as well as EN55032 class A. We offer the following types of this Mean Well series: NTS-300-212EU, NTS-300-224EU and NTS-300-248EU.

output: 300W
selectable output voltage: 200/220/230/240V AC
output voltage tolerance: ±3%
output frequency: 50/60Hz
output frequency tolerance: ±0,1%
curve shape: pure sine wave (THD<3%)
connection type: EU type F
operating temperature: -20 to +65°C
withstand voltage I/P-O/P: 3000V AC
withstand voltage O/P-FG: 1500V AC
dimensions: 210x130x55mm
weight: 1300g
