Mean Well LED driver series NPF-200V

LED drivers in a plastic housing (IP67) with a low no-load power consumption, a universal input, a constant voltage/constant current (CV/CC) and 200W. These flicker-free devices are protected against overvoltage...

Mean Well LED driver series NPF-200V

LED drivers in a plastic housing (IP67) with a low no-load power consumption, a universal input, a constant voltage/constant current (CV/CC) and 200W. These flicker-free devices are protected against overvoltage, overload, overtemperature as well as short circuit and are suitable for use as an emergency lighting control as well as for LED lighting applications. They comply with UL8750, EN61347-2-13, EN61347-1, IEC61347-2-13, IEC61347-1 as well as EN55015 and are suitable for use as an emergency lighting control as well as for LED lighting applications. We offer the following types of this Mean Well series: NPF-200V-12, NPF-200V-24, NPF-200V-36, NPF-200V-42, NPF-200V-48 and NPF-200V-54.

  • single output
  • output: 180 to 200,3W
  • input voltage: 100 to 350V AC (47 to 63Hz), 142 to 431V DC
  • input current: 1,1A
  • maximal input inrush current: 65A
  • no-load power consumption: <0,5W
  • leakage current: 0,25mA
  • connection type: Litze
  • cable length: 30cm
  • withstand voltage I/P-O/P: 3750V AC
  • operating temperature: -40 to +85°C
  • dimensions: 195x68x39,5mm
  • weight: 1030g
> More
Data Sheet
Showing 1 - 6 of 6 products
  • Product Stock Unit price Volume discounts
  • Mean Well
    NPF-200V-12, Mean Well LED drivers, 200W, IP67, constant voltage, dimmable, NPF-200V series
    43,99 €
    237638 NPF-200V-12 NPF-200V-12
    43,99 €
    Quantity Unit price
    50 + 42,59 €
    Stock: 27
  • Mean Well
    NPF-200V-24, Mean Well LED drivers, 200W, IP67, constant voltage, dimmable, NPF-200V series
    43,99 €
    237639 NPF-200V-24 NPF-200V-24
    43,99 €
    Quantity Unit price
    50 + 42,59 €
    Stock: 30
  • Mean Well
    NPF-200V-36, Mean Well LED drivers, 200W, IP67, constant voltage, dimmable, NPF-200V series
    43,99 €
    237640 NPF-200V-36 NPF-200V-36
    43,99 €
    Quantity Unit price
    50 + 42,59 €
    Stock: 10
  • Mean Well
    NPF-200V-42, Mean Well LED drivers, 200W, IP67, constant voltage, dimmable, NPF-200V series
    43,99 €
    237641 NPF-200V-42 NPF-200V-42
    43,99 €
    Quantity Unit price
    50 + 42,59 €
    Stock: 10
  • Mean Well
    NPF-200V-48, Mean Well LED drivers, 200W, IP67, constant voltage, dimmable, NPF-200V series
    43,99 €
    237642 NPF-200V-48 NPF-200V-48
    43,99 €
    Quantity Unit price
    50 + 42,59 €
    Stock: 56
  • Mean Well
    NPF-200V-54, Mean Well LED drivers, 200W, IP67, constant voltage, dimmable, NPF-200V series
    43,99 €
    237643 NPF-200V-54 NPF-200V-54
    43,99 €
    Quantity Unit price
    50 + 42,59 €
    Stock: 10
Showing 1 - 6 of 6 products
