Mean Well DC/DC converter series DDR-480

Converter modules in a DIN rail housing (TS-35/7.5 or 15) with 480W, an input voltage ratio of 2:1, 150% peak load capability and a regulated output voltage. These devices have a fanless design (cooling by free air convection) and are protected against short circuit, overload, overvoltage, overtemperature as well as voltage reversal. They have a width of 85,5mm and comply with EN55032 class A, UL62368-1 as well as IEC62368-1. We offer the following types of this Mean Well series: DDR-480B-12, DDR-480B-24, DDR-480B-48, DDR-480C-12, DDR-480C-24, DDR-480C-48, DDR-480D-12, DDR-480D-24 and DDR-480D-48.

single output
output: 400,8 to 480W
output voltage tolerance: ±1%
operating temperature: -40 to +80°C
withstand voltage I/P-O/P: 4000V DC
withstand voltage I/P-FG: 2500V DC
withstand voltage O/P-FG: 710V DC
dimensions: 85,5x125,2x128,5mm
weight: 1375g
