Mean Well LED driver series SLD-50

LED drivers in a plastic housing with a constant current/voltage (SLD-50-12/-24), 50W or a constant power (SLD-50-56). These devices comply with EN61347-1, EN61347-2-13, EN61000-3-2 class C as well as EN55015 and are protected against overload (auto recovery), overvoltage, overtemperature as well as short circuit. They are suitable for LED lighting applications and have a built-in active PFC function. We offer the follwing types of this Mean Well series: SLD-50-12, SLD-50-24 and SLD-50-56.

single output
output: 50,4W
input voltage: 110 to 305V AC (47 to 63Hz), 155 to 431V DC
maximal input inrush current: 50A
overcurrent protection (SLD-50-12/24): 95 to 108%
overload protection (SLD-50-56): 110 to 150%
withstand voltage (I/P-O/P): 3750V AC
operating temperature: -20 to +90°C
dimensions: 280x30x16,8mm
weight: 175g
