Recom DC/DC converter series R-78E-1.0

DC/DC converter modules in a SIL3 housing with 1A and partly with an epoxy resin seal (R-78E-1.0/X9). These devices are suitable for direct PCB mounting and have a high efficiency. They are protected against ...

Recom DC/DC converter series R-78E-1.0

DC/DC converter modules in a SIL3 housing with 1A and partly with an epoxy resin seal (R-78E-1.0/X9). These devices are suitable for direct PCB mounting and have a high efficiency. They are protected against short circuit and comply with IEC60950-1, EN60950-1 as well as EN55032 class A. We offer the following types of this Recom series: R-78E3.3-1.0, R-78E5.0-1.0 and R-78E12-1.0/X9.

  • single output
  • maximal output voltage tolerance: 5%
  • ripple and noise: 120mVpp
  • operating temperature: -40 to +85°C
  • weight: 2g
> More
Data Sheet
