Stannol solering wire series Kristall 611 TC

Colophony-free and halogen-activated soldering wires with high activity and good flow characteristics. They allow fast soldering, have a good wetting behavior on poorly solderable surfaces as well as ve...

Stannol solering wire series Kristall 611 TC

Colophony-free and halogen-activated soldering wires with high activity and good flow characteristics. They allow fast soldering, have a good wetting behavior on poorly solderable surfaces as well as very low flux splitting and leave slightly colored residues. These soldering wires are designed for automated and manual soldering.

  • melting range: 227°C
  • flux type (J-STD-004): REM1
  • flux content (EN 12224): 2,5%
  • halogen content: 1,1%
  • corrosive effects (DIN EN 61190-1-1): low
  • alloy (Flowtin TC): Sn99,3 Cu0,7
  • flux core: 1 core
> More
Data Sheet
