Mean Well LED driver series HBG-200

LED drivers in an aluminium housing (circular shape, IP65) with a universal input, 200W and a built-in potentiometer for adjusting the constant current. These devices are protected against overload (auto recovery), overvoltage as well as short circuit, are suitable for LED lighting applications and are not dimmable. They comply with EN61347-1, EN61347-2-13, EN55015, EN61000-3-2 class C as well as EN61000-3-3 and have a built-in active PFC function. We offer the following types of this Mean Well series: HBG-200-36A, HBG-200-48A and HBG-200-60A.

single output
output: 196,8 to 198W
input voltage: 90 to 305V AC (47 to 63Hz), 127 to 431V DC
maximal input inrush current: 85A
overcurrent protection: 95 to 108%
withstand voltage I/P-O/P: 3750V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 500V AC
operating temperature: -40 to +85°C
dimensions: Ø151,68x66,5mm
weight: 1530g
