Mean Well DC/DC converter series DDR-240

DC/DC converters with a 150% peak load capability, an adjustable DC output and an undervoltage lockout. These devices with a width of only 40mm, an input/output insulation of 4000V DC and an ultra wide input voltage ratio of 2:1 can be mounted on a DIN rails (TS-35/7.5 or 15) and have a cooling by free air convection. They are protected against overtemperature, overvoltage, overload as well as short circuit. We offer the following types of this Mean Well series: DDR-240B-24, DDR-240B-48, DDR-240C-24, DDR-240C-48, DDR-240D-24 and DDR-240D-48.

single output
output: 240W
overload protection: 105 to 135%
withstand voltage I/P-O/P: 4000V DC
withstand voltage I/P-FG: 2500V DC
withstand voltage O/P-FG: 710V DC
operating temperature: -40 to +70°C
weight: 760g

> More

Data Sheet
