Mean Well LED driver series LDC-80

LED drivers in an aluminium housing with a universal input, a constant power and 80W. These flickerfree SELV compliant devices are protected against overload (auto recovery), overvoltage as well as short circuit and comply with EN61000-3-2 class C, EN55015, EN61347-1 as well as EN61347-2-13. They are suitable for LED lighting applications and have a built-in active PFC function. We offer the following types of this Mean Well series: LDC-80 (not dimmable), LDC-80B (3 in 1 dimming function, 0 to 10V DC, PWM, potentiometer) and LDC-80DA (DALI, push dimming).

single output
output: 80W
input voltage: 180 to 295V AC (47 to 63Hz)
maximal input inrush current: 55A
no-load power: <0,5W
withstand voltage I/P-O/P: 3750V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 1500V AC
operating temperature: -25 to +85°C
dimensions: 360x30x21mm
weight: 295g
