Mean Well power supply series UHP-500

Power supplies in a metal case (U-bracket) with 500W, a slim/low profile (31mm), a fanless design and a universal input. These devices have a peak load capability of 150% (100ms), a built-in active PFC function and are protected against short circuit, overload (auto recovery), overvoltage as well as overtemperature. They are suitable for an operating altitude of up to 5000m and comply with EN55032 class B, UL/EN62368-1 as well as EN60335-1 (except UHP-500-55). We offer the following types of this Mean Well series: UHP-500-5, UHP-500-12, UHP-500-15, UHP-500-24, UHP-500-36, UHP-500-48 and UHP-500-55.

single output
output: 400 to 501,6W
input voltage: 90 to 264V AC (47 to 63Hz), 127 to 370V DC
maximal input inrush current: 60A
maximal leakage current: 0,75mA
overload protection: 110 to 140%
withstand voltage I/P-O/P: 3750V AC
withstand voltage I/P-FG: 2000V AC
withstand voltage O/P-FG: 1250V AC
operating temperature: -20 to +70°C
weight: 905g
